Speedflow 108-20-BLK | -20 AN 60° Hose End - Black

The Speedflow 108-20-BLK is a -20 AN hose end with a 60° formed bend and a black hard-coat anodised finish. Check the fitting dimensions and hose routing clearance for your installation.

Listed specifications

• Part number: 108-20-BLK
• Size: -20 AN
• Thread: 1-5/8-inch-12 UNF
• Angle: 60°
• Material: 6061-T6 billet aluminium
• Finish: Black hard-coat anodised
• Design: Formed bend, cutter-style hose end
• Manufacture: Australia

Hose compatibility

The listing identifies Speedflow 100 and 120 Series hose. Confirm the exact hose model, size and manufacturer-approved fitting combination for this part before ordering or assembly. The previous description's PTFE designation has not been verified and must not be used to select a hose.

Matching AN size alone does not establish hose compatibility. Confirm fluid suitability, working pressure, temperature and assembly requirements for the complete hose assembly. Do not assume suitability for a particular fuel, oil or other fluid system from the fitting size alone.

Assembly

Follow Speedflow's hose preparation, assembly and tightening instructions. Any rotation used for alignment during installation must not be assumed to permit continuous rotation in service. Inspect and test the completed assembly before use.
