Proflow EFI Pro Fuel Pressure Regulator 30-75 PSI 4-Port 2000HP Billet Aluminium (PFEFS13110)

Proflow EFI Pro Fuel Pressure Regulator - 4-Port 2000HP

The Proflow PFEFS13110 EFI Pro fuel pressure regulator delivers precise fuel pressure control for high-performance EFI systems up to 2000 horsepower. This premium billet aluminium regulator features a 4-port design with adjustable pressure from 30-75 PSI, making it perfect for street performance, racing, and forced induction applications.

Key Features

• Wide Pressure Range: Adjustable from 30-75 PSI for versatile applications
• 2000 HP Rated: Handles fuel flow requirements for high-horsepower builds
• 4-Port Design: Inlet, outlet, return, and gauge port for complete system integration
• CNC-Machined Billet Aluminium: Precision construction for leak-free performance
• 1:1 Rising Rate: Maintains consistent fuel pressure under boost conditions
• Easy Adjustment: Top-mounted adjustment screw with locking nut
• Universal Fitment: Works with most EFI systems and fuel pumps
• Premium Quality: Built to professional racing standards

Technical Specifications

• Pressure range: 30-75 PSI (adjustable)
• Flow capacity: 2000 HP
• Ports: 4-port configuration
• Material: CNC-machined billet aluminium
• Rising rate: 1:1 (boost referenced)
• Port threads: -6 AN or -8 AN (verify specific model)
• Adjustment: Top-mounted with lock nut
• Weight: 1kg

Applications

Perfect for high-performance EFI systems, turbocharged engines, supercharged applications, nitrous oxide systems, E85 conversions, race engines, and any application requiring precise, adjustable fuel pressure control up to 2000 horsepower.

Installation Note: The 1:1 rising rate design automatically increases fuel pressure in proportion to boost pressure when the vacuum/boost reference port is connected. For naturally aspirated applications, leave the reference port capped.

Perfect for: EFI conversions, LS swaps, turbo builds, supercharged engines, race cars, and any high-performance fuel system requiring reliable, adjustable pressure regulation.

Part number: PFEFS13110 | Barcode: 90014233 | Australian stock ready to ship.
