Collection: Speedflow 200 Series 45° AN Hose Ends

Browse black Speedflow 202 Series 45-degree AN hose ends from the 200 Series fitting range. These aluminium fittings are listed for use with Speedflow 200 Series PTFE braided hose.

Listed AN sizes

• -3 AN: 202-03-BLK
• -4 AN: 202-04-BLK
• -6 AN: 202-06-BLK
• -8 AN: 202-08-BLK
• -10 AN: 202-10-BLK
• -12 AN: 202-12-BLK

45-degree routing and construction

The listed fittings feature 6061 aluminium construction, formed bends and a black finish. Post-assembly rotation helps align the hose for installation.

Choose a 45-degree hose end where the hose needs an angled exit from the connection. Check fitting clearance, the planned hose run and the hose manufacturer's minimum bend radius before choosing the angle.

Match the PTFE hose series

Match both the AN connection size and the specified Speedflow 200 Series hose. A matching dash size or stainless braid alone does not establish compatibility with another hose construction or brand.

Use the assembly components and procedure specified by Speedflow for the exact part. Do not substitute fittings from another hose series based on size alone.

Confirm the complete hose and fitting assembly is suitable for the intended fluid, working pressure and temperature. Do not assume suitability for brake, clutch or other hydraulic systems without explicit manufacturer confirmation for the exact assembly. Follow Speedflow's assembly and installation instructions.
