Proflow AirMax Intake Manifold – Aluminium, Natural, Square Bore, Ford 302/351 Cleveland Dual Plane | PFEM7564

Proflow AirMax Intake Manifold – PFEM7564

The Proflow AirMax dual-plane intake manifold is purpose-built for Ford 302 and 351 Cleveland engines, delivering a cooler, denser air/fuel charge through its signature air-gap runner design. Whether you're on the street or the strip, this manifold gives your Cleveland the breathing room to make real power from idle to redline.

Key Features

• Unique air-gap design separates runners from engine heat, keeping the charge cooler and denser for improved combustion efficiency
• Tuned dual-plane runners for strong throttle response and peak power from 1,500 to 6,500 RPM
• Compatible with both 2V and 4V cast iron Cleveland heads — broad fitment across the Cleveland family
• 4-barrel square bore carburettor flange for wide carb compatibility
• Die-cast high-quality aluminium for strength, precision, and weight savings
• Natural silver finish — ready to run or paint to match your build
• No EGR — clean, race-focused design

Specifications

• Part Number: PFEM7564
• Fuel System: Carburetted
• Type: Dual Plane
• Carburettor: Single, 4-Barrel Square Bore
• Application: Ford SB 302 & 351 Cleveland (2V & 4V Cast Iron Heads)
• RPM Range: 1,500 – 6,500 RPM
• Material: Die-Cast Aluminium
• Finish: Natural / Silver
• Overall Height: 5.02"
• EGR: No
• Weight: 7 kg

The natural finish PFEM7564 is the go-to choice for builders who want a clean, versatile intake that performs on both the street and the track.
