816-12-08-BLK -12 Flare to 1/2" NPT Adapter

Speedflow 816-12-08-BLK | -12 AN Flare to 1/2" NPT Adapter — Black Anodised

For the most demanding high-flow plumbing circuits, the Speedflow 816-12-08-BLK bridges the gap between large-bore -12 AN hose ends and 1/2" NPT ported components. Precision machined from high-grade aluminium and finished in black hard anodise, this adapter is built for serious motorsport and performance automotive applications — from dry-sump oil systems and high-capacity fuel delivery to large engine block ports and transmission cooler circuits where maximum flow and a leak-free seal are non-negotiable.

Why Choose the Speedflow 816-12-08-BLK?

• Precision CNC machined aluminium — consistent thread form and 37° JIC/AN flare seating for a reliable, leak-free connection
• Black hard anodised finish — heat, corrosion, and fluid resistant for long-term reliability in the harshest engine bay environments
• -12 AN female flare to 1/2" NPT male — connects large-bore -12 AN hose ends to 1/2" NPT ported components
• 37° JIC/AN flare seat — mates correctly with all standard -12 AN swivel hose ends for a positive seal
• Maximum flow capacity — the large -12 AN bore ensures unrestricted flow for high-volume oil, fuel, and coolant circuits
• 1/2" NPT male thread — suits the large NPT ports found on engine blocks, oil pans, gearbox casings, and high-flow system components

Ideal Applications

Dry-sump oil system plumbing, high-capacity fuel delivery lines, large engine block and oil pan ports, transmission and gearbox oil cooler connections, differential cooler circuits, and any application requiring a -12 AN to 1/2" NPT conversion.

Specifications

• Part Number: SF816-12-08-BLK
• AN End: -12 AN Female Flare (37° JIC)
• NPT End: 1/2" NPT Male
• Finish: Black Hard Anodised Aluminium
• Type: AN Flare to NPT Adapter

Stock held locally in Perth, WA — fast dispatch Australia-wide.
